| Configuration | 90 |
|---|---|
| Connection of Hyd Component | Swivel Female |
| Cut-off (mm) | 52.0 MMT |
| Head1/Head2 Dimens. | -1024 |
| Drop Length (mm) | 56.0 MMT |
| Dash Size of Hose | 10 |
| Group of Hydraulic Fittings | AG Standard Fittings |
| Nom ID-Hose (inch) | 5/8" INH |
| Nom ID-Hose (mm) | 16.0 MMT |
| Nut Hexagon (mm) | 30.0 MMT |
| Type of Nut | Thrust wire nut |
| OD-Hyd Tube (mm) | 16 |
| Weight (kg) | 0.209 KGM |
| Termination of Hyd Component | D24S |
| O-ring Presence on Termination | Oring Std |
| Thread Dash Size | 24 |
| Thread Size | M24X1.5 |
